SD700
POWER ELECTRONICS
68
MODBUS COMMUNICATION
Parameter
Screen
Description
Address
Range
Modbus Range
G4.3.1
1 SENSOR 2 ?=N
Sensor of Analogue Input 2 enable
40269
N
Y
0 to 1
G4.3.2
2 SENSOR 2=Bar
Selection of sensor 2 units
40273
%
l/s
m³/s
l/m
m³/m
l/h
m³/h
m/s
m/m
m/h
Bar
kPa
Psi
m
ºC
ºF
ºK
Hz
rpm
0 to 18
G4.3.3
3 AIN2 FORMAT=mA
Analogue Input 2 format
40265
V
mA
0 to 1
G4.3.4
4 Inmin2=+4mA
Minimum range of Analogue Input 2
40249
-10V to G4.3.6
+0mA to G4.3.6
-10000 to +10000
0 to +20000
G4.3.5
5 Smi2=+0.0Bar
Minimum range of sensor 2
40255
-3200 to G4.3.7
Engineering Units
-32000 to +32000
G4.3.6
6 Inmax2=+20mA
Maximum range of Analogue Input 2
40245
G4.3.4 to +10V
G4.3.4 to +20mA
-10000 to +10000
0 to +20000
G4.3.7
7 Sma2=+10.0Bar
Maximum range of sensor 2
40251
G4.3.5 to +3200
Engineering Units
32000 to +32000
G4.3.8
8 SPD LO2=+0%
Speed for the minimum range of Analogue
Input 2
40247
-250% to G.4.3.9
-20480 to +20480
G4.3.9
9 SPD HI2=+100%
Speed for the maximum range of Analogue
Input 2
40243
G4.3.8 to +250%
-20480 to +20480
G4.3.10
10 FB2 = +0.0Bar
Minimum operating range of sensor
40257
-3200 to G4.3.12
Engineering Units
-32000 to +32000
G4.3.11
11 FB2-SP = 0%
Minimum speed range for sensor in open
loop
40261
-250% to +250%
-250 to +250
G4.3.12
12 FA2 = +10.0Bar
Maximum operating range of sensor
40253
G4.3.10 to +3200
Engineering Units
-32000 to +32000
G4.3.13
13 FA2-SP = 100%
Maximum speed range for sensor in open
loop
40259
-250% to +250%
-250 to +250
G4.3.14
14 AIN2 LOSS=N
Protection for Analogue Input 2 loss
40267
N
Y
0 to 1
G4.3.15
15 2_Z BAND=OFF
Zero band filter for Analogue Input 2
40271
OFF=0.0; 0.1 to 2.0%
9 to 163
G4.3.16
16 FILTER2=OFF
Low Pass filter for Analogue Input 2
40275
OFF = 0.0; 0.1 to
20.0%
0 to 200
G4.4.1
1 Sensr U=l/s
Sensor units of Pulse Input
40581
%
l/s
m³/s
l/m
m³/m
l/h
m³/h
m/s
m/m
m/h
0 to 9
G4.4.2
2 Pls/s = 100l/s
Flowmeter configuration
40582
0 to 32760 Flow Units
0 to 32760
G4.4.3
3 M Rn=1000l/s
Maximum range of flow meter
40583
0 to 32760 Flow Units
0 to 32760
G4.6.1
1 FIBER MODE = 0
Fiber Mode
41251
MAS
SLV
NON
0 to 2
G4.6.3.5
5 CONTROL = NONE
Control
41254
NONE
START
RUN
0 to 2
G4.6.3.6
6 FAULT = N
Control (Master)
41255
N
Y
0 to 1
G4.6.3.7
7 SPIN STP = N
SPIN STOP (Slave)
41256
N
Y
0 to 1
G4.6.5
5 T/O F.O = 0
Time out optical fiber (Slave)
41253
OFF, 0.10 to 9.99
0 to 10
G5.1
1 ACC1=5.0%/s
Acceleration ramp 1
40392
0.01 to 650% / sec
1 to 65000
G5.2
2 DECEL1=1.0%/s
Deceleration ramp 1
40394
0.01 to 650% / sec
1 to 65000
