Page #71 background imageLoading...
Page #71 background image
SD700
MODBUS COMMUNICATION
69
Parameter
Screen
Description
Address
Range
Modbus Range
G5.3
3 ACC2=10.0%/s
Acceleration ramp 2
40393
0.01 to 650% / sec
1 to 65000
G5.4
4 DECEL2=10.0%/s
Deceleration ramp 2
40395
0.01 to 650% / sec
1 to 65000
G5.5
5 BRK ACC=OFF
Speed for acceleration ramp change
40396
OFF; 0 to 250%
0 to 20480
G5.6
6 BRK DEC=OFF
Speed for deceleration ramp change
40397
OFF; 0 to 250%
0 to 20480
G5.7
7 MPT INC1=1.0%/s
Ramp 1 of reference increase for motorized
pot.
40400
0.01 to 650% / sec
10 to 65000
G5.8
8 MPT DEC1=3.0%/s
Ramp 1 of reference decrease for motorized
pot.
40399
0.01 to 650% / sec
10 to 65000
G5.9
9 MPT INC2=1.0%/s
Ramp 2 of reference increase for motorized
potentiometer
40398
0.01 to 650% / sec
10 to 65000
G5.10
10 MPT DEC2=3.0%/s
Ramp 2 of reference decrease for motorized
potentiometer
40401
0.01 to 650% / sec
10 to 65000
G5.11
11 MPOT BRK = OFF
Speed for ramp change with motorized pot.
40402
OFF=0 to 250%
0 to 20480
G5.12
12 SP FLT=0.250s
Time constant to filter the speed
40403
OFF, 0.0 to 80.0%
0 to 60000
G6.1
1 SEL REF=MREF
Source selection for introducing reference
signal
40142
NONE
AI1
AI2
RESERV
MREF
LOCAL
locPID
COMMS
0 to 8
G6.2
2 PID LOC=+100%
PID local reference
40149
+0.0% to +400%
0 to 32760
G6.3
3 SEL FBK=AI2
Selection of feedback signal source
40143
NONE
AI1
AI2
AI1+AI2
COMMS
MtrTrq
AbsMTq
Mtr I.
MtrPwr
BUSVdc
PhiCos
0 to 11
G6.4
4 GAIN Kp=8.0
Proportional gain of PID control
40144
0.1 to 20
1 to 200
G6.5
5 INTEGRAL = 0.0s
Integration time of PID control
40145
0.0 to 1000s; Max
0 to 10000; 10001
G6.6
6 DIFFEREN = 0.0s
Derivation time of PID control
40146
0.0 to 250s
0 to 2500
G6.7
7 INVERT PID=N
PID output inversion
40147
N
Y
0 to 1
G6.8
8 Filt FB = OFF
Low pass filter
40150
OFF=0 to 20s
0 to 200
G6.9
9 ERR PID = +0.0%
PID control error
40148
-400 to 400%
-32768 to 32767
G7.1
1 STOP 1 = RAMP
Stop mode 1
40003
RAMP
SPIN
0 to 1
G7.2
2 STOP 2 = SPIN
Stop mode 2
40004
RAMP
SPIN
0 to 1
G7.3
3 BRK STP 2 = OFF
Changing speed for stop mode
40005
OFF=0 to 250%
0 to 20480
G7.4
4 START = RAMP
Start mode
40002
RAMP
SPIN
SPIN2
0 to 2
G7.5
5 START 2=RAMP
Start mode 2
40015
RAMP
SPIN
SPIN2
0 to 2
G7.6
6 STAR DLY = OFF
Start delay time
40006
OFF=0 to 6500s
0 to 65000
G7.7
7 STOP DLY = OFF
Stop delay time
40007
OFF=0 to 6500s
0 to 65000
G7.8
8 STP MIN SP = N
Minimum stop speed
40008
N
Y
0 to 1
G7.9
9 OFFdly = OFF
Delay time between stop and next start
40014
OFF=0.000 to 10.0s
0 to 10000
G7.10
10 RUN AFTR VFL = N
Run after occurring power loss
40009
N
Y
0 to 1
G7.11
11 SPNstr B = OFF
Accuracy setting for Starting by Spin
40017
OFF=0;1 to 10%
0 to 1000
G7.12
12 OFFdly2 = OFF
Delay time for start command after stop
40031
OFF=0; 0.1 to
6500.0s
0 to 65000
G7.13
13 STR AFT RST=N
Starting after fault reset with start command
40010
N
Y
0 to 1
G7.14
14 RPWr OFF = OFF
Power Off Delay
41852
OFF, 0.001 to 9.99
0-9990
G7.15
15 MagneT = OFF
Magnetization time
40404
OFF, 0.001 to 9.99
0-9990
G7.16
16 RetATR = OFF
Start Delay after Reset.
41561
OFF, 0.001 to 9.99
0-9990
G8.1.1
1 SEL RELAY 1=02
Selection of Relay 1 control source
40362
00 to 45
0 to 45
G8.1.2
2 T R1 ON=0.0s
ON delay time for Relay 1
40363
0.0 to 999s
0 to 9999
G8.1.3
3 T R1 OFF=0.0s
OFF delay time for Relay 1
40364
0.0 to 999s
0 to 9999
