SD700
POWER ELECTRONICS
70
MODBUS COMMUNICATION
Parameter
Screen
Description
Address
Range
Modbus Range
G8.1.4
4 INVERT REL1=N
Relay 1 inversion
40365
N
Y
0 to 1
G8.1.5
5 SEL RELAY 2=03
Selection of Relay 2 control source
40366
00 to 45
0 to 45
G8.1.6
6 T R2 ON=0.0s
ON delay time for Relay 2
40367
0.0 to 999s
0 to 9999
G8.1.7
7 T R2 OFF=0.0s
OFF delay time for Relay 2
40368
0.0 to 999s
0 to 9999
G8.1.8
8 INVERT REL2=N
Relay 2 inversion
40369
N
Y
0 to 1
G8.1.9
9 SEL RELAY 3=05
Selection of Relay 3 control source
40370
00 to 45
0 to 45
G8.1.10
10 T R3 ON=0.0s
ON delay time for Relay 3
40371
0.0 to 999s
0 to 9999
G8.1.11
11 T R3 OFF=0.0s
OFF delay time for Relay 3
40372
0.0 to 999s
0 to 9999
G8.1.12
12 INVERT REL3=N
Relay 3 inversion
40373
N
Y
0 to 1
G8.1.13
13 CRAspdOF=+5.0%
Speed for disconnecting relay in option Crane
40597
+0.0% to +250%
0 to 20480
G8.1.34
34 Dig Out FB = DO1
Digital Output Feedback
41155
DO1
DO2
DO3
0 to 2
G8.1.35
35 DlyDoFB = 1.0s
Delay Digital Output Feedback
41156
0.5 to 60s
5 to 600
G8.1.36
36 FAULT1 = OFF
Closure of digital output “FAULT1”
41151
0 to 90
0 to 90
G8.1.37
37 FAULT2 = OFF
Closure of digital output “FAULT2”
41152
0 to 90
0 to 90
G8.1.38
38 FAULT3 = OFF
Closure of digital output “FAULT3”
41153
0 to 90
0 to 90
G8.1.39
39 FAULT4 = OFF
Closure of digital output “FAULT4”
41154
0 to 90
0 to 90
G8.2.1
1 ANLG OUT1=01
Mode selection for Analogue Output 1
40342
00 to 27
0 to 27
G8.2.2
2 FORMT 1=4-20 mA
Format selection for Analogue Output 1
40343
0-10V
±10V
0-20mA
4-20mA
0 to 3
G8.2.3
3 MIN1 RNG=+0%
Low of range selection Analogue Output 1
40344
-250% to +250%
-20480 to +20480
G8.2.4
4 MAX1 RNG=+100%
High range selection of Analogue Output 1
40345
-250% to +250%
-20480 to +20480
G8.2.5
5 FILTER 1=OFF
Filter selection for Analogue Output 1
40346
OFF= 0.0 to 20.0s
0 to 200
G8.2.6
6 ANLG OUT 2=02
Mode selection Analogue Output 2
40347
00 to 27
0 to 27
G8.2.7
7 FORMT 2=4-20 mA
Format selection for Analogue Output 2
40348
0-10V
±10V
0-20mA
4-20mA
0 to 3
G8.2.8
8 MIN2 RNG=+0%
Low range selection of Analogue Output 2
40349
-250% to +250%
-20480 to +20480
G8.2.9
9 MAX2 RNG=+100%
High range selection of Analogue Output 2
40350
-250% to +250%
-20480 to +20480
G8.2.10
10 FILTER 2=OFF
Filter selection for Analogue Output 2
40351
OFF=0.0 to 20.0s
0 to 200
G9.1.1
1 COMP 1 SEL=00
Source selection for Comparator 1
40302
00 to 22
0 to 22
G9.1.2
2 COMP 1 TYPE=0
Comparator 1 type selection
40303
0 to 1
0 to 1
G9.1.3
3 SP C1 ON=+100[%]
Activation value of Comparator 1 in Normal
mode
40305
-250% to +250%
-20480 to +20480
G9.1.4
4 LIM 2 C1=+100[%]
Limit 2 for Comparator 1 in Window mode
40305
-250% to +250%
-20480 to +20480
G9.1.5
5 LIM 1 C1=+0[%]
Limit 1 for Comparator 1 in Window mode
40304
-250% to +250%
-20480 to +20480
G9.1.6
6 T C1 ON=0.0s
ON delay time for Comparator 1
40306
0.0 to 999s
0 to 9999
G9.1.7
7 SP C1 OF=+0[%]
Deactivation value of Comparator 1 in Normal
mode
40304
-250% to +250%
-20480 to +20480
G9.1.8
8 T C1 OF=0.0s
OFF delay time for Comparator 1
40307
0.0 to 9999s
0 to 99999
G9.1.9
9 SEL FUNT C1=00
Selection of output function for Comparator 1
40308
00 to 15
0 to 15
G9.2.1
1 COMP 2 SEL=00
Source selection for Comparator 2
40311
00 to 22
0 to 22
G9.2.2
2 COMP 2 TYPE=0
Comparator 2 type selection
40312
0 to 1
0 to 1
G9.2.3
3 SP C2 ON=+100[%]
Activation value of Comparator 2 in Normal
mode
40314
-250% to +250%
-20480 to +20480
G9.2.4
4 LIM 2 C2=+100[%]
Limit 2 for Comparator 2 in Window mode
40314
-250% to +250%
-20480 to +20480
G9.2.5
5 LIM 1 C2=+0[%]
Limit 1 for Comparator 2 in Window mode
40313
-250% to +250%
-20480 to +20480
G9.2.6
6 T C2 ON=0.0s
ON delay time for Comparator 2
40315
0.0 to 999s
0 to 9999
G9.2.7
7 SP C2 OF=+0[%]
Deactivation value of Comparator 2 in
Normal mode
40313
-250% to +250%
-20480 to +20480
G9.2.8
8 T C2 OF=0.0s
OFF delay time for Comparator 2
40316
0.0 to 9999s
0 to 99999
G9.2.9
9 SEL FUNT C2=00
Selection of output function for Comparator 2
40317
00 to 15
0 to 15
G9.3.1
1 COMP 3 SEL=00
Source selection for Comparator 3
40320
00 to 22
0 to 22
G9.3.2
2 COMP 3 TYPE=0
Comparator 3 type selection
40321
0 to 1
0 to 1
G9.3.3
3 SP C3 ON=+100[%]
Activation value of Comparator 3 in Normal
mode
40323
-250% to +250%
-20480 to +20480
G9.3.4
4 LIM 2 C3=+100[%]
Limit 2 for Comparator 3 in Window mode
40323
-250% to +250%
-20480 to +20480
G9.3.5
5 LIM 1 C3=+0[%]
Limit 1 for Comparator 3 in Window mode
40322
-250% to +250%
-20480 to +20480
G9.3.6
6 T C3 ON=0.0s
ON delay time for Comparator 3
40324
0.0 to 999s
0 to 9999
G9.3.7
7 SP C3 OF=+0[%]
Deactivation value of Comparator 3 in Normal
mode
40322
-250% to +250%
-20480 to +20480
G9.3.8
8 T C3 OF=0.0s
OFF delay time for Comparator 3
40325
0.0 to 9999s
0 to 99999
G9.3.9
9 SEL FUNT C3=00
Selection of output function for Comparator 3
40326
00 to 15
0 to 15
