SD700
POWER ELECTRONICS
72
MODBUS COMMUNICATION
Parameter
Screen
Description
Address
Range
Modbus Range
G14.1
1 MREF 1=+10.0%
Multi-reference 1
40052
-250% to +250%
-20480 to +20480
G14.2
2 MREF 2=+20.0%
Multi-reference 2
40053
-250% to +250%
-20480 to +20480
G14.3
3 MREF 3=+30.0%
Multi-reference 3
40054
-250% to +250%
-20480 to +20480
G14.4
4 MREF 4=+40.0%
Multi-reference 4
40055
-250% to +250%
-20480 to +20480
G14.5
5 MREF 5=+50.0%
Multi-reference 5
40056
-250% to +250%
-20480 to +20480
G14.6
6 MREF 6=+60.0%
Multi-reference 6
40057
-250% to +250%
-20480 to +20480
G14.7
7 MREF 7=+70.0%
Multi-reference 7
40058
-250% to +250%
-20480 to +20480
G15.1
1 INCH1=+0.00%
Inch speed 1
40092
-250% to +250%
-20480 to +20480
G15.2
2 INCH2=+0.00%
Inch speed 2
40093
-250% to +250%
-20480 to +20480
G15.3
3 INCH3=+0.00%
Inch speed 3
40094
-250% to +250%
-20480 to +20480
G16.1
1 SKIP 1=+0.0%
Skip frequency 1
40132
-250% to +250%
-20480 to +20480
G16.2
2 SKIP 2=+0.0%
Skip frequency 2
40133
-250% to +250%
-20480 to +20480
G16.3
3 SKIP BAND=OFF
Skip bandwidth
40134
OFF=0 to 20%
0 to 1638
G17.1
1 T DC BRAKE=OFF
Time for DC brake activation
40025
OFF=0.0 to 99s
0 to 990
G17.2
2 DC CURR=0%
Current applied to the brake
40022
0 to 100%
0 to 8192
G17.3
3 DC VOLTS=0.0%
Voltage applied to the brake
40023
0.0 to 25%
0 to 2048
G17.4
4 I HEATING=OFF
Non condensing heating current
40024
OFF=0.0 to 30%
0 to 2458
G17.5
5 DYN BRAK=N
Use of external brake
40026
N
Y
0 to 1
G18.0
0 ENCODER = NO
Encoder
40475
N
Y
0 to 1
G18.1
1 PULSES=1024
Pulses per revolution of the encoder
40337
200 to 8191
200 to 8191
G18.2
2 TYPE=DIFF
Encoder Type
40473
DIFF
SING
0 to 1
G18.3
3 ENCOD FILTER=N
Encoder filter selection
40474
Yes
NO
0 to 1
G19.1.1
1 TYPE CRTL=V/Hz
Selection of control type
40522
V/Hz
VECT
0 to 1
G19.1.2
2 VECTOR CTR = PMC
Vector Control mode
40535
PMC
AVC
0 to 1
G19.1.3
3 PMC = OL SP
Power Motor Control mode
40526
OL SP
OL TQ
CL SP
CL TQ
1 to 4
G19.1.4
4 AVC = CL SP
Advance Vector Control mode
40527
CL SP
CL TQ
3 to 4
G19.1.5
5 FRQ=4000Hz
Commutation frequency
40523
4000 to 8000 Hz
4000 to 8000
G19.1.6
6 PEWAVE=Y
Pewave control
40524
N
Y
0 to 1
G19.1.8
8 AUTOTUNE=N
Motor parameter auto-tuning
40486
N
Y
0 to 1
G19.1.9
9
OVERMODULATIO=N
Over-modulation
40493
N
Y
0 to 1
G19.2.1
1 MIN FLUX = 100%
Minimum Flux
40502
40 to 100%
3277 to 8192
G19.2.3
3 V BOOST = 0.0%
Initial voltage
40592
0.0 to 100%
0 to 8192
G19.2.4
4 SLIP COMPENS=N
Slip compensation
40505
N
Y
0 to 1
G19.2.7
7 I SLIP=2.0%
Current limit factor
40508
0.0 to 20.0%
0 to 1638
G19.2.9
9 STR FRQ = 0.0%
Initial frequency
40594
0.0% to 100%
0 to 8192
G19.2.11
11 DAMPref=10%
Damping reference
40506
0 a 10%
0 to 819
G19.2.13
13 CT Vbus = 800
Regeneration bus voltage
40021
For Vin = 230v,
390 to 410
For VIN = 400V / 500V
625 to 800V
For VIN = 690V
950 to 1251V
Real value = Modbus
value
G19.3.1
1 R STR=1%
Stator resistance (Rs)
40482
0.0 to 9.9%
0 to 811
G19.3.2
2 R. RTR = 0%
Rotor resistance (Rr)
40530
0.0% to 15%
0 to 15000
G19.3.3
3 Lm = 40%
Magnetizing inductance (Lm)
40531
40% to 800%
3276 to 65535
G19.3.4
4 L.I = 0%
Stray Inductance
40534
0.0% to 50%
0 to 4096
G19.3.5
5 FL WEAK = 90%
Weakening field
40532
50% to 100%
4096 to 8192
G19.4.1
1 Kp Sp = 95%
Closed loop proportional speed constant.
40334
0.0% to 100%
0-8192
G19.4.2
2 Ki Sp = 95%
Speed closed loop integration time setting.
40335
0.0% to 100%
0-8192
G19.4.3
3 Kp Tq = 95%
Torque proportional closed loop constant.
40331
0.0% to 100%
0-8192
G19.4.4
4 Ki Tq = 95%
Torque closed loop time setting.
40332
0.0% to 100%
0-8192
G19.4.5
5 Kp I = 95%
Current closed loop proportional constant
40528
0.0% to 100%
0 to 8192
G19.4.6
6 Ki I = 15%
Current closed loop integration time setting
40529
0.0% to 100%
0 to 8192
G19.4.9
9 Flux tune=2.0%
Flux tuning
40333
0.0% to 10%
0-100
G20.0.1
1 COM CONTROL=0
Communications Control
40042
0-6
0-6
G20.1.1
1 COMMS T/O=OFF
Communication timeout MODBUS RTU
40413
OFF=0 to 250s
0 to 250
G20.1.2
2 COMM ADDR=10
Communication address
40414
1 to 255
1 to 255
