MODBUS COMMUNICATION
73
Parameter
Screen
Description
Address
Range
Modbus Range
G20.1.3
3 BAUDS=9600
Communication speed
40415
600
1200
2400
4800
9600
19200
38400
0 to 6
G20.1.4
4 PARITY=NONE
Communication parity
40416
ODD
NONE
EVEN
0 to 2
DispBR=4800
Display communication speed
40417
1200
2400
4800
9600
1 to 4
G20.2.1
1 NODE ADDR=10
Slave address in Profibus network
40852
1 to 255
1 to 255
G20.3.1
1 CO NODEID=0
Canopen slave address
41501
0-127
0-127
G20.3.2
2 CO BAUD=1Mbps
Bus speed connected to equipment
41502
1Mbps
10mbps
125mbps
250mbps
500mbps
0-4
G20.3.3
3 CO REF sp=+0.0%
Canopen Speed
41503
-
-32768 to +32768
G20.4.1
1 DN MAC ID=0
Devicenet MAC ID
41701
0-63
0-63
G20.4.2
2 DNBaud=500kbps
Devicenet Baud rate
41702
125kbps
250kbps
500kbps
0-2
G20.4.3
3 CONTROL MODE=
Control modes
41401
0-2
0-2
G20.4.4
4 REFEREN MODE=0
Reference modes
41402
0-2
0-2
G20.4.5
5 FAULT MODE =2
Fault Mode
41404
FAULT
IGNORE
PE BEHV
0-2
G20.4.6
6 ASM IN=70
Input assembly
41704
70
71
100
150
151
152
0-5
G20.4.7
7 ASM- OUT=20
Output assembly
41705
20
21
100
0-2
G20.4.8
8 DNst=UNUSED
DeviceNet State
41703
0 to 4
0-4
G20.5.1
1 B/R F.O = 1 Mbps
Bus Speed connected to drive
41252
0 to 3
0-3
G20.6.1
01 Reg01 = 40001
Register 1
41966
40001-45400
40001-45400
G20.6.2
02 Reg02 = 40001
Register 2
41967
40001-45400
40001-45400
G20.6.3
03 Reg03 = 40001
Register 3
41968
40001-45400
40001-45400
G20.6.4
04 Reg04 = 40001
Register 4
41969
40001-45400
40001-45400
G20.6.5
05 Reg05 = 40001
Register 5
41970
40001-45400
40001-45400
G20.6.6
06 Reg06 = 40001
Register 6
41971
40001-45400
40001-45400
G20.6.7
07 Reg07 = 40001
Register 7
41972
40001-45400
40001-45400
G20.6.8
08 Reg08 = 40001
Register 8
41973
40001-45400
40001-45400
G20.6.9
09 Reg09 = 40001
Register 9
41974
40001-45400
40001-45400
G20.6.10
10 Reg10 = 40001
Register 10
41975
40001-45400
40001-45400
G20.6.11
11 Reg11 = 40001
Register 11
41976
40001-45400
40001-45400
G20.6.12
12 Reg12 = 40001
Register 12
41977
40001-45400
40001-45400
G20.6.13
13 Reg13 = 40001
Register 13
41978
40001-45400
40001-45400
G20.6.14
14 Reg14 = 40001
Register 14
41979
40001-45400
40001-45400
G20.6.15
15 Reg15 = 40001
Register 15
41980
40001-45400
40001-45400
G20.6.16
16 Reg16 = 40001
Register 16
41981
40001-45400
40001-45400
G20.6.17
17 Reg17 = 40001
Register 17
41982
40001-45400
40001-45400
G20.6.18
18 Reg18 = 40001
Register 18
41983
40001-45400
40001-45400
G20.6.19
19 Reg19 = 40001
Register 19
41984
40001-45400
40001-45400
G20.6.20
20 Reg20 = 40001
Register 20
41985
40001-45400
40001-45400
G20.6.21
21 Reg21 = 40001
Register 21
41986
40001-45400
40001-45400
G20.6.22
22 Reg22 = 40001
Register 22
41987
40001-45400
40001-45400
G20.6.23
23 Reg23 = 40001
Register 23
41988
40001-45400
40001-45400
G20.6.24
24 Reg24 = 40001
Register 24
41989
40001-45400
40001-45400
G20.6.25
25 Reg25 = 40001
Register 25
41990
40001-45400
40001-45400
G20.6.26
26 Reg26 = 40001
Register 26
41991
40001-45400
40001-45400
G20.6.27
27 Reg27 = 40001
Register 27
41992
40001-45400
40001-45400
G20.6.28
28 Reg28 = 40001
Register 28
41993
40001-45400
40001-45400
G20.6.29
29 Reg29 = 40001
Register 29
41994
40001-45400
40001-45400
