Power Electronics SD700 Series User Manual

POWER ELECTRONICS
SD700
MODBUS COMMUNICATION
77
Parameter
Screen
Description
Address
Modbus Range
SV1.1
Sp Ref =+000%
Value of present speed reference.
40162
8192 = 100% of motor rated speed
SV1.2
Tq Ref=000
Torque Reference Value
41316
-20480 to +20480
SV1.3
Mtr Speed = +0rpm
It shows the motor speed in rpm.
40169
Real value = Modbus value
SV1.4
Mtr Sp = +0.0%
It shows the motor speed in %.
40170
8192 = 100% of motor rated speed
SV1.5
Mtr Freq = +0.0Hz
Frequency at which motor is running.
40167
Real value = Modbus value
SV1.6
Mtr Vout = 0V
It shows the present voltage applied to the
motor.
40166
Real value = Modbus value
SV1.7
Mtr Iout = 0.0A
Present current flowing to the motor.
40163
Real value = (Modbus value / 10)
SV1.8
Mtr Torqe = 0.0%
It shows the present torque applied to the motor.
40164
8192 = 100% of motor rated torque
SV1.9
Mtr Pfactr = 0.0
It shows the power factor of the motor.
40168
Real value = (Modbus value / 10)
SV1.10
Mtr Pwr = +0.0kW
Instantaneous power consumption of the motor.
40165
Real value = (Modbus value / 10)
SV1.11
0.0A 0.0A 0.0A
Instantaneous current per phase of the motor
(U, V y W).
40177  U
40178  V
40179  W
Real value = (Modbus value / 10)
SV1.12
Vmt= 0 0 0V
Compound Instantaneous voltage (UV, VW,
UW).
40180  UV
40181  VW
40182  UW
Real value = Modbus value
SV1.13
PTC Motor = 0
It shows if the motor PTC is connected or not.
40218
0 to 1
SV1.14
Motor T. = 0.0%
Theoretical heating level of the motor.
40173
8192 = 100% of motor temperature
SV1.15
Enco. Pulso = 0
It shows the encoder pulses
40337
Real value = Modbus value
SV1.16
Clsped = 0 rpm
Real speed measured by the encoder
40336
Real value = Modbus value
SV2.1
390 390 390V
Input instantaneous voltage.
40183  RS
40184  ST
40185  RT
Real value = Modbus value
SV2.2
Inp Vol = 390V
Average input voltage to the drive.
-
Non accessible from this SW version
SV2.3
50.0 50.0 50.0Hz
Frequency of input voltage.
40159  RS
40160  ST
40161  RT
Real value = (Modbus value / 10)
SV2.4
Bus vol = 540V
DC Link voltage of the drive.
40171
Real value = Modbus value
SV2.5
IGBT Temp =+23ºC
Temperature measured at the power stage.
40172
Real value = Modbus value
SV2.6
Drive Temp =+26ºC
Internal temperature of the drive.
40240
Real value = (Modbus value / 100)
SV3.1
ANLG IN1 = +0.0V
Average value of the Analogue Input 1.
40186
Real value = (Modbus value / 1000)
SV3.2
AIN1 Refr = +0.00%
Speed reference or PID setpoint proportional to
the AI1.
40190
8192 = 100% maximum range of the
Analogue Input 1
SV3.3
AIN1 S = +0.00l/s
Value of sensor 1 associated to the AI1.
40262
Real value = (Modbus value / 10)
SV3.4
ANLG IN2 = +0.0V
Average value of the Analogue Input 2.
40187
Real value = (Modbus value / 1000)
SV3.5
AIN2 Refr = +0.00%
Speed reference or PID setpoint proportional to
the AI2.
40191
8192 = 100% maximum range of the
Analogue Input 2
SV3.6
AIN 2 S = +0.00Bar
Value of sensor 2 associated to the AI2.
40263
Real value = (Modbus value / 10)
SV3.7
ANL OUT1 = +4.0mA
It shows the value of the Analogue Output 1.
40192
Real value = (Modbus value / 1000)
SV3.8
AOUT1 Refer = +0.0%
Value of the magnitude associated to the AO1.
40194
8192 = 100% maximum range of the
Analogue Output 1
SV3.9
ANL OUT2 = +4.0mA
It shows the value of the Analogue Output 2.
40193
Real value = (Modbus value / 1000)
SV3.10
AOUT2 Refer = +0.0%
Value of the magnitude associated to the AO2.
40195
8192 = 100% maximum range of the
Analogue Output 2
SV3.11
Dl: 000000 0
Digital Inputs and PTC status.
40196
LSB  BIT0  MFI1
BIT6  PTC
0 to 1
SV3.12
Relays 1-3: X0X
Output relays status.
40197
BIT 0  R1; Range from 0 to 1
BIT 1  R2; Range from 0 to 1
BIT 2  R3; Range from 0 to 1
SV3.13
Speed M = +0.000m/s
Machine speed associated to the motor (speed
motor in engine. Units).
-
SV3.14
Modbus Traffic:O
Traffic in user port (Modbus RTU)
40418
0 to 1
SV3.15
Display_traffi = 0
Presence of the Display Unit
40422
0 to 1
SV4.1
Actual Fault = 00
Present code fault.
40235
Fault number
SV4.2
Drive Curr = 170A
Drive rated current.
40209
Real value = (Modbus value / 10)
SV4.3
Drive Volt = 400V
It shows the drive rated voltage.
40210
Real value = (Modbus value / 10)
SV4.4
S/W
Software version installed into the equipment.
40206
Real value = Modbus value
SV4.5
H/W y.y
It shows the hardware version of the equipment.
40207
Real value = (Modbus value / 100)
SV4.6
PID R% = +0.0%
PID setpoint value of the equipment standard
program.
40204
8192 = 100% maximum range of AI
SV4.7
PID F% = +0.0%
PID feedback value of the equipment standard
program.
40205
8192 = 100% maximum range of AI
