CONFIGURATION REGISTER
95
PARAMETERS
FACTORY SETTINGS
SETTING 1
SETTING 2
3 MIN2 SP=-100%
SPEED MIN LIMIT2
-100%
___________________
___________________
4 MAX2 SP=+100%
SPEED MAX LIMIT2
+100%
___________________
___________________
5 I LIMIT=___A
MAX CURRENT
___A
___________________
___________________
6 I LIM TO = OFF
TIMOUT MAX CURRE
OFF
___________________
___________________
7 I. MAX2=____A
MAX CURRENT 2
___A
___________________
___________________
8 MI2 brSP=OFF
MAX CURR BRK SPD
OFF
___________________
___________________
9 MAX TOR=+150%
MAX TORQUE
+150%
___________________
___________________
10 T LIM TO=OFF
TIMEOUT MAX TORQ
OFF
___________________
___________________
11 INVERSION?=N
N
___________________
___________________
12 ILIM RGN=OFF
CURR.LIMIT.RGN
OFF
___________________
___________________
13 Ilim_rgnTO=OFF
ILim.Regen.Tmout
OFF
___________________
___________________
14 T/I LIM SP = N
N
___________________
___________________
15 Rg TQ L = 150%
150%
___________________
___________________
G11: Protections
1 SP LIM_TO=OFF
TMAX LIMITIN SPD
OFF
___________________
___________________
2 STOP TO=OFF
TIMEOUT STOPPING
OFF
___________________
___________________
3 GND I LIMIT=10%
GND CURR MAX LEV
10%
___________________
___________________
4 LOW VOLT=360V
LO INPUT VOLTAGE
360V
___________________
___________________
5 LOW V TO=5s
LO INP VOL TIMEO
5s
___________________
___________________
6 HIGH VOLT=500V
HI INPUT VOLTAGE
500V
___________________
___________________
7 HI V TO=5s
HI INP VOL TIMEO
5.0s
___________________
___________________
8 Dlasy VO = OFF
VOUT asyTRIP DLY
OFF
___________________
___________________
9 LOW V BHV=1
1
___________________
___________________
10 PTC EXT ?=N
N
___________________
___________________
11 PUMP OV=20.0A
PUMP OVERLOAD LV
20.0A
___________________
___________________
12 PMovl FIL=OFF
PMP OVL FILTER
OFF
___________________
___________________
13 Povl DLY=OFF
PMP OVERLOAD DLY
OFF
___________________
___________________
14 UNDERLOAD=N
N
___________________
___________________
15 ULD CUR=___A
UNDERLOAD CURREN
___A
___________________
___________________
16 ULD SPD=+100%
UNDERLOAD SPEED
+100%
___________________
___________________
17 ULD DELY=10s
UNDERLOAD DELAY
10s
___________________
___________________
18 DEC.SPdly=OFF
DECREM.SPD.DELAY
OFF
___________________
___________________
19 Sp.SRCH.I =10%
SPD.SEARCH INCR.
10%
___________________
___________________
21 MSpeedT = OFF
OFF
___________________
___________________
22 Dasy IO = 5.0s
5.0s
___________________
___________________
