Chapter 2: Installation

Figure 1. Connectors on the FastTrak TX4650 card

Figure 2. Connectors on the FastTrak TX2650 card

TX4650

I2C/SMBus Connector

for SuperSwap

Port 3

FastTrak TX4650 card

Global LED

Connectors

Port 1

Port 4

Port 2

Individual LED

Connectors

TX2650

I2C/SMBus Connector

for SuperSwap

FastTrak TX2650 card

Global LED

Connectors

Port 1

Port 2

Individual LED

Connectors
