Pyronix Matrix 832 Installation Guide

Matrix 832 / 832+ / 424
Page 100 RINS428-5
10.2.5 Local Up / Down Loading Session (RS232)
Local up/downloading can take place via the on-board RS232 port. In order for the panel to see the local PC
this function must be started. The panel busy display will be shown on the keypad while the PC is connected
to the panel and the devices on the KD line will become totally unusable, this includes all outputs and
keypads. If no PC is found or the PC is disconnected the remote devices will recommence operation within 30
seconds.
SUPPLY
FAU L T
ARMED
P.A.READY
TAMPER
FIRE
DAY
ALARM
8
8
A
BCD
2
1
34
S
ET
FUNC
P.
A
.
FIRE
5678
90
Keypad Programming Procedure
10.2.6 Engineer Code NVM Reset to Factory Default
Enter BYW. Three tones will be heard and a further three beeps after approximately 15 seconds.
10.2.7 Programmable Outputs Test
Enter BYWT followed by [01 - 12]*. Press C button to toggle the state of the output. Press B to exit the
option and restore outputs. An acceptance tone will be played.
[01]…[12]* = PGM1 to PGM12,
10.2.8 Walk Test
Enter BYWU followed by [1 - 4]*. Press B to exit the option.
[1 - 4]* = Arm Mode A, B, C, D.
10.2.9 Scan For Devices On the Bus
Enter BYWV to scan for all devices on bus.
10.2.10 Local Up / Down Loading using RS232 Output
Enter BYWW to initiate a local up / down loading session.
