Pyronix Matrix 832 Installation Guide

! Matrix 832 / 832+ / 424
RINS428-5 Page 3
1.1.2 Additional Expanders
PROGRAMMABLE OUTPUT EXPANDERS
TRANSISTOR MX-ROX8T
Supply Voltage
13.8V typical (9-16V range)
Supply Current
45mA +/- 5 % @13.8V
Outputs
Type
Open Collector
Maximum Switching Voltage
12Vdc
Maximum Switching Current
225mA
RELAY MX-ROX8R
Supply Voltage
13.8V typical (9-16V range)
Supply Current
225mA +/- 5 % @13.8V
Outputs
Type
N/O / N/C contacts
Maximum Switching Voltage
30V
Maximum Switching Current
1A
PROGRAMMABLE ZONE EXPANDERS
LOCAL PLUG-ON MX-IX16
Supply Voltage
13.8V typical (9-16V range)
Supply Current
15mA@ +/- 5 % 13.8V
Zone Loop Current
Zone Activation Resistance
See main control panel data
REMOTE MX-RIX with Zone Analyser
Supply Voltage
12V typical (9-16V range)
Supply Current
45mA +/- 5 % @13.8V
Zone Loop Current
Zone Activation Resistance
See main control panel data
PROGRAMMABLE VOICE MODULE
MX-VOICE
Supply Voltage
13.8V typical (9-16V range)
Supply Current
25mA +/- 5 % @13.8V
