Pyronix Matrix 832 Installation Guide

Matrix 832 / 832+ / 424
Page 152 RINS428-5
12.12.4 Decibell Connection to Matrix 832
NVM Reset
Relay
17V~ +BAT- B+ B- BT GT NC C NO1/ PG M1 PG M2 PG M3 PG M4 KD Z1 Z2 Z3 Z4 COM COM +AUX- Z5 Z6 Z7 Z8 COM COM RING
TIP R-1 T-1
BA
STB
TF
BT
B-
B+
DECIBELL
IMPORTANT
The Decibell may be connected / programmed
using different programmable outputs.
In this instance PGM1 is programmed as
“Externa Bell”, and PGM2 is programmed as
“Strobe” - See section 8.11
PGM1 = BA = BELL OUTPUT
PGM1 = STB = STROBE TRIGGER
1
7
V
A
C
O
u
t
p
u
t
+
-
B
A
T
12.12.5 Decibell Connection to Matrix 424
BA
STB
TF
BT B-
B+
DECIBELL
IMPORTANT
The Decibell may be connected / programmed using
different programmable outputs.
The Bell Tamper must be connected to a spare zone
programmed as ‘Tamper’ - in this case Z1
In this instance PGM1 is programmed as “External Bell”
and PGM2 is programmed as “Strobe” - See section 8.11
PGM1 = BA = BELL OUTPUT
PGM2 = STB = STROBE TRIGGER
+
-
B
AT
+BELL-
Bell Fu se 1 Amp
PGM1 PGM2 PGM3 PGM4
17V AC
Output
+BAT-
KD Z1 COM COM Z2 +AUX- Z3 Z4 RING TIP R-1 T-1
17V~
