Matrix 832 / 832+ / 424
Page 60 RINS428-5
7.11 Partition Options
PC Programming Procedure
The PC window below shows partition options 1 and 2 for partition 1 of the PC software. On the left hand side
of this screen shot is a partition selection box, which should be used to change between desired partitions. 1,
2, 3 and 4.
Information in one partition can be copied into other partitions by selecting a partition number in the partition
selection box and clicking the “>>” button. Once all desired options have been chosen, press <save> and
proceed to the next window.
MEANING
Programmable Options Explanation
Partition Options 1
PA Alarm
Silent - If the Personal Attack zone is activated in silent mode the internal or external sounders will not sound.
Dial out will occur if the panel has been programmed to do so.
Audible - The Personal Attack zone activation will cause both internal and external sounders to operate. Dial
out will also occur if the panel has been programmed to do so.
Spare
Not used (options may be added in future development).
Tamper Alarm
Internal And External - This option will cause both internal (keypad sounders) and external sounders to
activate on a tamper alarm when the panel is in disarmed mode.
Internal Only - This option will cause only the internal (keypad sounders) sounder to activate upon a tamper
alarm when the panel is in disarmed mode. In armed mode both sounders will always operate
To Next Page
