Pyronix Matrix 832 Installation Guide

! Matrix 832 / 832+ / 424
RINS428-5 Page 65
Common Partition Programming
Auto Arm Partition When These Partitions Arm (Partition Dependency)
In some instances there is a need to program one or more partitions as common partitions. For instance if we
use partition 2, 3 and 4 to protect 3 separate flats we might need to use partition 1 as a common partition
protecting the lobby area. In order to achieve this we need to program the following options:
1. Allocate user code 2 to partition 1+2, allocate user code 3 to partition 1+3, allocate user code 4 to
partition 1+4.
2. Program the partition dependency option so that partition 1 arms when partition 2, 3 and 4 are armed in
away mode.
3. If 3 keypads are used – one in each flat - allocate keypad 2 to partition 1+2, Allocate keypad 3 to partition
1+3, allocate keypad 4 to partition 1+4.
Arming Partition
To arm for instance partition 2 enter user code number 2, then select partition 2 from the keypad and
press FUNC to confirm the procedure. The partition will start arming. When partition 2+3+4 are armed
in away mode partition 1 that is common will arm automatically.
Disarming Partition
To disarm for instance partition 2 enter your user code 2, them disarm partition 2, to disarm partition 3
enter user code 3 and disarm partition 3, to disarm partition 4 enter user code 4 and disarm partition 4.
When partition 2,3 or 4 disarm, the common partition (1) will disarm automatically
Number of Re-arms
Number of times the partition will re-arm automatically after the bell timer expires. “0” stands for
continuous arming after alarm.
SUPPLY
FAU L T
ARMED
P.A.READY
TAMPER
FIRE
DAY
ALARM
8
8
A
BCD
2
1
34
S
ET
FUNC
P.
A
.
FIRE
5678
90
Keypad Programming Procedure
7.12.1 Exit Terminator Type for Arm Mode A
Enter BVW followed by one digit for the desired partition number [1 - 4]. The current Arm type will be
displayed. To select the type of arm mode enter [00], [01] or [02]. To save the changes press
B. An
acceptance tone will be played.
Default
Arm Mode Description
Partition 1 Partition 2 Partition 3 Partition 4
00 Timed Exit On On On On
01 Final Exit Off Off Off Off
02 Silent Arm Off Off Off Off
03 Push to Arm Off Off Off Off
04 Forced Arm Off Off Off Off
7.12.2 Exit Terminator Type for Arm Mode B
Enter BVW followed by one digit for the desired partition number [1 - 4]. The current Arm type will be
displayed. To select the type of arm mode enter [00], [01] or [02]. To save the changes press
B. An
acceptance tone will be played.
Default
Arm Mode Description
Partition 1 Partition 2 Partition 3 Partition 4
00 Timed Exit On On On On
01 Final Exit Off Off Off Off
02 Silent Arm Off Off Off Off
03 Push to Arm Off Off Off Off
04 Forced Arm Off Off Off Off
