Matrix 832 / 832+ / 424
Page 110 RINS428-5
11.4.9 12.4.9 Online Panel Information
Shows maintenance information about the panel when connected. Shows the status of each
partition, zones, devices and faults.
Partition Information
Shows information for each partition. Press the 1 to 4 buttons to get information on each partition. A Green
circle shows which mode the panel is in apart from Alarm, which is shown as a Red circle. The Partset that
the panel is currently in is also shown.
The panel can also be armed or disarmed from this screen. The panel will either Arm or Disarm depending on
its current status. Press the “Send Arm/Disarm Command” button to either Arm or Disarm the panel.
NOTE: If you have set the Arm Mode to “Final Door” the panel will not Arm!
Fault Information
An orange circle is shown next to the text if there is a panel fault.
The battery voltage is also shown. If a battery is missing then this value may show as a positive voltage, this
is due to the way it is calculated. If Battery Missing is shown then the voltage shown is not valid.
Zone Information
Open and Close is displayed depending on the state of the zone. This screen shows all 32 zones that are
available. If a zone is not on the panel, these are still shown (i.e. you do not have Zone Doubling selected but
zones 16 to 32 are still shown).
A map of the system can also be shown from this screen. An open zone will be highlighted on the map in
Red.
Devices
This shows the 6 devices on the bus. ID will be number from 1 to 4 denoting the number of the device. OK
shows whether the device is communicating with the panel.
Next to the LCD Keypads only there is a button called “More”. Press this to get additional information about
the keypads available languages is displayed.
NOTE: It is possible using the UDL Software to set an LCD Keypad to a language that it doesn’t
support, the keypad will remain displaying in the same language as before.
Also shown is the Current Language the LCD Keypad is displaying, and a list of the available 8 languages that
the keypad can actually display.
