Pyronix Matrix 832 Installation Guide

Matrix 832 / 832+ / 424
Page 2 RINS428-5
Matrix 832+ Matrix 832 Matrix 424
FUSES
Bell fuse
Quick blow 1A – F1L Quick blow 1A – F1L Quick blow 1A – F1L
Aux fuse
Quick blow 1A – F1L Quick blow 1A – F1L N/A
Keypad fuse
Quick blow 1A – F1L N/A N/A
Battery fuse
Slow blow 5A – T5H N/A N/A
BATTERY
Type
12V Lead acid
rechargeable
12V Lead acid
rechargeable
12V Lead acid
rechargeable
Battery Charge
Min 6V Min 6V Min 6V
Maximum Battery Charge
Current
800mA (Metal Case)
350mA (Plastic case)
350mA 350mA
Battery Charge Method
The Matrix panel monitors the voltage of the battery and commences
charging when the battery reaches 12.8V +/- 5% and disables charging
when it reaches 13.6V +/- 5%.
Battery Capacity
Metal Enclosure
2.8 to 17Ah
Plastic Enclosure
2.8 to 7Ah
Plastic Enclosure
2.8 to 7Ah
Plastic Enclosure
2.8 to 7Ah
BAT Terminal Protection
Short circuit & battery
reverse protection.
Short circuit & battery
reverse protection.
Short circuit & battery
reverse protection.
Low Battery Detect Level
10.7V +/- 0.2V 10.7V +/- 0.2V 10.7V +/- 0.2V
Battery Cutoff Level
10.4V +/- 0.2V
(With MX-BATT)
10.4V +/- 0.2V
(With MX-BATT)
10.4V +/- 0.2V
(With MX-BATT)
MECHNICAL
Security Grade
2 (Metal Case)
N/A (Plastic Case)
N/A N/A
Environmental Class
2 (Metal Case)
N/A (Plastic Case)
N/A N/A
Dimensions
Plastic
340 x 280 x 94.5 mm 340 x 280 x 94.5 mm 340 x 280 x 94.5 mm
Metal
389.5 x 314.5 x
96.2mm
N/A N/A
TEMPERATURE
Operational Metal Case
-10 to +55ºC
14 to 131ºF
Plastic Case
0 to +40ºC
32 to 104ºF
0 to +40ºC
32 to 104ºF
0 to +40ºC
32 to 104ºF
Storage
-20 to +60ºC
-4 to 172ºF
-20 to +60ºC
-4 to 172ºF
-20 to +60ºC
-4 to 172ºF
Maximum Humidity
93% Rh (Metal Case) N/A N/A
