Pyronix Matrix 832 Installation Guide

Matrix 832 / 832+ / 424
Page 56 RINS428-5
7.9.2.3 Change Label Messages on LCD keypad
NOTE: This option allows the engineer to edit and change the text on all available label messages.
There are 32 (01 – 32) different labels that can be selected. The engineer can edit any of these labels.
Enter
BUWV. The following display will be shown.
MATRIX
SELECT LABEL 01
DISARMED
Use the F and G keys to choose the required label and enter B to select it. The following display will
now be shown.
MATRIX
EDIT TEXT 01
DISARMED
Use the F and G keys to scroll the flashing key along the label text to edit. Use the numerical number
keys on the keypad to change the text. Press
B to accept the changes. Press @ to exit this option. See the
keymap table on page 48 for details on how to obtain all of the available alphanumeric characters.
LCD RKP – Editable Label Text and Allocation Table
Keypad Label No. Default Text Allocation
LCD (ID1) 1 DISARMED LCD Keypad (ID1) Day message
LCD (ID2) 2 DISARMED LCD Keypad (ID2) Day message
LCD (ID3) 3 DISARMED LCD Keypad (ID3) Day message
LCD (ID4) 4 DISARMED LCD Keypad (ID4) Day message
LCD (ID1) 5 ARMED LCD Keypad (ID1) Armed message
LCD (ID2) 6 ARMED LCD Keypad (ID2) Armed message
LCD (ID3) 7 ARMED LCD Keypad (ID3) Armed message
LCD (ID4) 8 ARMED LCD Keypad (ID4) Armed message
None 9 LABEL Spare
None 10 LABEL Spare
None 11 LABEL Spare
None 12 LABEL Spare
None 13 LABEL Spare
None 14 LABEL Spare
None 15 LABEL Spare
None 16 LABEL Spare
None 17 LABEL Spare
None 18 LABEL Spare
None 19 LABEL Spare
None 20 LABEL Spare
None 21 LABEL Spare
None 22 LABEL Spare
None 23 LABEL Spare
None 24 LABEL Spare
None 25 LABEL Spare
None 26 LABEL Spare
LCD (ID1) 27 PULSE PGM 1 LCD Keypad (ID1) Pulse PGM message
LCD (ID2) 28 PULSE PGM 2 LCD Keypad (ID2) Pulse PGM message
LCD (ID3) 29 PULSE PGM 3 LCD Keypad (ID3) Pulse PGM message
LCD (ID4) 30 PULSE PGM 4 LCD Keypad (ID4) Pulse PGM message
LCD (ID1-ID4) 31 WELCOME Top line Engineer Mode entry message
LCD (ID1-ID4) 32 ENGINEER Bottom line Engineer Mode entry message
