SECTION 3
OPERATING PRINTER
48
b. Select your desired Document Options and Printer Features.
Print Optimizations: Enabled, Disabled
Make sure Enabled is selected.
Print inverted: No, Yes
No = normal – right-side-up to operator
Yes = inverted (rotate 180°)
NOTE: If you select “Yes” to print “inverted”, the “Head”
numbers, in your “Template” (Layout), will not be displayed
correctly. In this case Head #6 should be identified as the
head at the top of the Layout and Head # 1 should be
identified as the head at the bottom of the Layout.
Resolution: 150, 200, 300, 600 DPI (print quality)
Belt Speed: Low, Medium, Medium High, High
NOTE: Belt Speed selections are limited by the current Resolution selection.
Do NOT select choices marked with CAUTION symbol.
Compatible Belt Sped Selections
Low, Medium and Medium High, High
Low, Medium and Medium High
TIP: Compatible Belt Speeds can also be selected at the printer, after sending the job. Pause printer
before selecting a new Belt Speed.
Feed Delay:
Feeder pause time (1/10 of a second). 10 = 1 second.
Printer will pause feeder, for set value, between each piece of media that is fed/printed. Use to provide
more dry-time between pieces.
Click on OK to close the above windows.
9. Click on “Print” to send job to the printer.
NOTE: Make sure the printer is powered up and ready, before
clicking on the "Print" button.
TIP: Start by choosing “Current Page” to print a single piece, to
check print locations.
Please contact BCC Software (Customer Support: 800-624-5234) or
visit their web site (www.bccsoftware.com) for additional help on
using Bulk Mailer.
