APPENDIX
133
Appendix G – Adjustable Exit Wheels Assembly
The Adjustable Exit Wheels Assembly (part # 47-900-10) is an optional accessory that must be installed by a
qualified service technician.
It permanently replaces the existing “Exit Transport Cover”.
47-900-10 Exit Wheel Assembly Kit includes:
(1) Right-hand Wheel Assembly
(1) Left-hand Wheel Assembly
(1) Exit Wheel Shaft
(2) Mounting screws
This optional accessory provides the ability to position the Wheel Assemblies so they avoid rolling over freshly
printed surfaces, which can reduce or eliminate ink tracking and smearing.
NOTICE: You may NOT need this accessory. You may be able to avoid ink tracking and smearing by unlocking
(unlock, don’t open) the “Exit Transport Cover”. Unlocking the “Exit Transport Cover” may NOT work for all
applications, without causing feeding issues, which is why this accessory was designed and made available.
