692 Appendix D Format Reference
VESA CVT Formats
SMT0660 640 x 480 Progressive 31.469 59.941 25.1752
SMT0660D 640 x 400 Progressive 31.469 59.941 25.1752
SMT0760H 720 x 400 Progressive 31.469 59.941 28.3221
SMT0760V 720 x 480 Progressive 31.469 59.941 28.3221
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
CVR0660 640 x 480 Progressive 29.375 59.464 23.500
CVR0760 768 x 480 Progressive 29.634 59.866 27.500
CVR0860 800 x 600 Progressive 36.979 59.837 35.500
CVR0860H 848 x 480 Progressive 29.514 59.745 29.750
CVR0960D 960 x 600 Progressive 37.054 59.957 41.500
CVR1060 1024 x 768 Progressive 47.297 59.870 56.000
CVR1060H 1064 x 600 Progressive 36.969 59.820 45.250
CVR1160D 1152 x 720 Progressive 44.398 59.916 58.250
CVR1260 1280 x 960 Progressive 59.201 59.920 85.250
CVR1260D 1224 x 768 Progressive 47.327 59.907 65.500
CVR1260E 1280 x 768 Progressive 47.396 59.995 68.250
CVR1260G 1280 x 1024 Progressive 63.194 59.957 91.000
CVR1260H 1280 x 720 Progressive 44.444 59.979 64.000
CVR1360H 1360 x 768 Progressive 47.368 59.960 72.000
CVR1460 1400 x 1050 Progressive 64.744 59.948 101.000
CVR1560D 1536 x 960 Progressive 59.257 59.977 100.500
CVR1660 1600 x 1200 Progressive 74.006 59.924 130.250
CVR1660D 1680 x 1050 Progressive 64.674 59.883 119.000
CVR1760D 1728 x 1080 Progressive 66.605 59.950 125.750
CVR1760H 1704 x 960 Progressive 59.147 59.865 110.250
CVR1860H 1864 x 1050 Progressive 64.723 59.929 131.000
CVR1960 1920 x 1440 Progressive 88.822 59.974 184.750
CVR1960D 1920 x 1200 Progressive 74.038 59.950 154.000
CVR1960H 1920 x 1080 Progressive 66.587 59.934 138.500
CVR2060 2048 x 1536 Progressive 94.769 59.980 209.250
CVR2160H 2128 x 1200 Progressive 74.082 59.986 169.499984
CVR2360D 2304 x 1440 Progressive 88.778 59.945 218.750
CVR2460D 2456 x 1536 Progressive 94.706 59.940 247.750
CVR2560 2560 x 1920 Progressive 118.474 59.987 322.250016
CVR2560E 2560 x 1536 Progressive 94.761 59.975 257.750
CVR2560H 2560 x 1440 Progressive 88.787 59.951 241.500
CVR2760H 2728 x 1536 Progressive 94.789 59.993 273.750016
CVR3060D 3072 x 1920 Progressive 118.425 59.962 382.749984
CVR3260 3200 x 2400 Progressive 148.140 60.000 497.749984
CVR3460H 3408 x 1920 Progressive 118.484 59.992 422.749984
