208 Appendix A Command Reference
Special Sync Probe Pulse
Color Look-Up Table (LUT)
HDMI
Data Island Packet
InfoFrame Packet
Command Description
PSHD Set line delay (in pixels)
PSPG Enable/disable probe pulse on special sync output
PSPM Set lines in frame where probe pulse occurs
PSPP Set probe pulse polarity
PSPW Set pixel width
PSVD Set vertical delay
PSVW Set vertical width
Command Description
RGBW Set RGB levels to within the current lookup table
SLUT Set colorset for color lookup table
Command Description
XACR Set Audio Clock Regeneration packet
XGDP Set Generic Control packet
XGCP Enable/disable Audio/Video Mute (AVMUTE) in general control packet
MUTE Enable/disable Audio/Video Mute (AVMUTE) feature
DPTG Set gated packet types
DPTR Set frequency for General Control packet
DPGU Update generator with current data island packet content
Command Description
XGIF Set Generic (Vendor-Specific) InfoFrame packet data
XAVI Set Auxiliary Video Information (AVI) InfoFrame packet data
