Quantum Data 881 User Manual

118 Chapter 13 Testing HDCP on HDMI
The features provided by the EST are specifically used for the following tests:
List of Tests
The following table describes the HDCP compliance tests performed with the 882EA.
Index Test EST Function
1 1A_01 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Verifies that the encryption enable/disable pulse
is transmitted during the valid period, that no data
islands, video data or guard band is transmitted
during the keep-out period and that no data island
is transmitted during Line Key Calc period on the
encrypted frame.
11 1B_01 (Transmitter Downstream
w/Repeater)
Verifies that the encryption enable/disable pulse
is transmitted during the valid period, that no data
islands, video data or guard band is transmitted
during the keep-out period and that no data island
is transmitted during Line Key Calc period on the
encrypted frame.
20 2C_04 (Receiver Upstream
w/Transmitter) (w/DVI
Transmitter)
Positions the encryption enable pulse in the
vsync or vertical blanking at three different loca-
tions (beginning, center and end).
21 3A_01 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Verifies that the encryption enable/disable pulse
is transmitted during the valid period, that no data
islands, video data or guard band is transmitted
during the keep-out period and that no data island
is transmitted during Line Key Calc period on the
encrypted frame.
26 3B_01 (Repeater Downstream
w/Repeater)
Verifies that the encryption enable/disable pulse
is transmitted during the valid period, that no data
islands, video data or guard band is transmitted
during the keep-out period and that no data island
is transmitted during Line Key Calc period on the
encrypted frame.
Index Test Description
1 1A_01 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Regular Procedure: With HDMI Capable
Receiver
2 1A_02 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Regular Procedure: HDCP_HPD After Writing
Aksv
3 1A_03 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Regular Procedure: HDCP_HPD After Starting
Third Part of Authentication
4 1A_04 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Irregular Procedure: (First Part of Authentication)
HDPC Port Access
