882 Video Test Instrument User Guide (Rev A.35) 163
Format Editor - Menu Buttons
The activation buttons of the Format Editor are shown in the window below.
The following table describes the Format Editor menu buttons.
Button Description
Connect Clicking on this button enables you to establish a connection between the
Format Editor and the 882E. A dialog pops up to enable you to enter the IP
address of the 882E you wish to connect to. This is equivalent to selecting
the Instrument Connect pull down menu.
New Format Opens up the New Format at the Timing tab. Enables you to create new
formats. This is equivalent to selecting the New Format from the File menu.
New Report Opens up the Report Format window. This is equivalent to selecting New
Report from the File menu. Enables you to view list of formats and their
primary parameters.
New Source Menu Opens up the Source Menu. This is equivalent to selecting New Source
from the File menu.
Open Enables you to browse to and open an xml format file on your PC. This is
equivalent to selecting Open from the File menu.
Save Enables you to save an xml format file on your PC. This is equivalent to
selecting Save from the File menu.
