Viewing generator configuration information
You can view information about a generator’s configuration, including the firmware and
gateware revisions, installed options, board serial numbers, and so on. The procedure for
accessing this information depends on the type of information you want.
• For information about the main board and video board memory, use the front panel.
• For complete generator statistics, view the GenStats image.
• For firmware and gateware versions, use the command line interface.
This section describes the procedures for accomplishing these methods of accessing
generator configuration information.
To view generator configuration information using the front panel:
1. Press the Tools key. The Tools menu appears on the generator’s display as shown
below.
2. Choose the System item by pressing the adjacent soft key. The System menu appears
on the generator’s display.
3. Choose the About item by pressing the adjacent soft key. A following message
appears on the generator’s display as shown below.
4. Press the Settings key. The main board information appears. Press the soft key
adjacent to the arrow by Serial Number to see other information about the main board.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
CEC
CalFactor Host
Network About
Serial Gpib
BootFrom Init
About the Phoenix
Press Settings
About
Main Board ->
Serial Number ->
39298E000000
To Next Page
