882 Video Test Instrument User Guide (Rev A.35) 107
Testing DVI displays with HDCP
This section describes how to test DVI and HDMI receivers with HDCP.
To set up the 882 for testing a DVI display:
1. Connect an HDMI-to-DVI converter cable between the HDMI OUT connector on the
882 and the device’s DVI receiver.
2. Activate the HDMI-D interface on the output port as follows:
a. Press the Interface key. A listing of signal interfaces appears on the 882’s display
as shown below.
b. Choose the HDMI-D item by pressing the adjacent soft key. The interface is
activated, and the port outputs the currently selected image and format.
Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 3 // Activates the HDMI-D interface
ALLU // Applies the interface setting to the 882
3. Choose a standard format (for example, DMT0660) by pressing the adjacent soft key.
Alternatively, you can load the format with the following command:
FMTL DMT0660
FMTU
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*
HDMI-H
