122 Chapter 13 Testing HDCP on HDMI
There are several configurations depending on what type of HDCP device you are testing.
Procedures for each are provided below.
Running HDCP compliance test on HDMI transmitters
To run the 1A and 1B series HDCP compliance tests on an HDMI source (transmitter):
Note: For the 882E, the 1A-08 test requires that you use the SRM disc for the 1A-08 test
if the source device has an optical drive. Refer to “To run the 1A-08 HDCP compliance test
using the SRM disc:” on page 700.
45 3C_II_08 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater)
Irregular Procedure: (Second Part of
Authentication) MAX_DEVS_EXCEEDED
46 3C_II_09 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater)
Irregular Procedure: (Second Part of
Authentication) MAX_CASCADE_EXCEEDED
Index Test Description
