Quantum Data 881 - Deleting an Image Catalog

882 Video Test Instrument User Guide (Rev A.35) 233
2. Press the Options key repeatedly until the Library folder appears on the generator’s
display as shown below:
3. Choose the Library item by pressing the adjacent soft key. The image library appears
as shown below. Each item in the image library is an image catalog.
4. Press the soft key adjacent to a catalog to enable or disable it. A + sign next to the item
indicates the item is enabled; a - sign indicates it is disabled.
5. Press the Content key to see the images in the selected catalogs.
To remove an image from a catalog:
1. Establish a session with the generator using either HyperTerminal over a serial
connection or Telnet over an Ethernet LAN.see “Establishing a terminal session with
the 882” on page 30 or “Establishing a Telnet session with the 882” on page 33.
2. To remove an image from a catalog, enter the following commands:
DIRL /tffs0/Library/ImageLib/TVImages // loads the TVImages catalog
DIRT ContentLib // identifies directory as a content directory
DIRB // begins a directory editing session
NAMK /cache0/Library/Images/TVImages/SMPTE133.img
Or...
NAMY 1 // deletes SMPTE133 (index 1)
DIRE // ends the directory editing session
DIRS // saves the catalog
Deleting an image catalog
You can delete an image catalogs either through the command line or through the
Generator FTP Browser. Procedures for both methods are provided below.
Library
-TVImages FPDImages-
SMPTE133 SMPTEBar
TVBar100 PulseBar
Regulate Geom_1
