882 Video Test Instrument User Guide (Rev A.35) 583
XAVI
Auxiliary Video Information InfoFrame Data
Class InfoFrame Packet
Description Writes Auxiliary Video Information (AVI) InfoFrame packet data.
Command syntax
(individual
parameter)
XAVI:aviparameter value
Command syntax
(complete
packet–version 1)
XAVI type version length [S [B [A [Y [R [M [C [SC [ETB [SBB [ELB [SRB ]]]]]]]]]]]]
Command syntax
(complete
packet–version 2)
XAVI type version length [S [B [A [Y [R [M [C [SC [ETB [SBB [ELB [SRB [VIC [PR [RGB
[EC [ITC [CN ]]]]]]]]]]]]]]]]]]
type
2
version
1 = version 1
2 = version 2
length (bytes)
13
The remaining are AVI Infoframe data parameters (aviparameter) as specified in
EIA/CEA-861-B standard, Section 6.1:
VERS (same as Version)
Infoframe version:
1 = version 1
2 = version 2
S
Scan information (see EIA/CEA-861-B standard, Table 8 for settings)
S1 S0 Scan Information
0 0 No Data
0 1 Overscanned (television)
1 0 Underscanned
(computer)
11 Future
