882 Video Test Instrument User Guide (Rev A.35) 207
Edit
DIDL Load an EDID from a file
DIDA Save an EDID to a specified filename
DIDU Update hardware with current EDID contents
DIDK Delete a saved EDID file
DIDP Set default EDID path
EDA Read/write EDID from/to device connected to HDMI output port
EDID? Read EDID from connected device
I2CR? Read EDID data using I2C bus
I2CW Write EDID data using I2C bus
XDID Set new EDID structure (DVI/HDMI Analyzer)
EDE Set HDMI input port with contents of EDID buffer (DVI/HDMI Analyzer)
STRG Enable/disable SCL low signal stretching (DVI/HDMI Analyzer)
Command Description
DIDN Create a new EDID file
DIDB Begin an EDID editing session
XDID Set new EDID structure (DVI/HDMI Analyzer)
DIDE End an EDID editing session
DIDS Save a new EDID to filename specified by DIDN
Command Description
