882 Video Test Instrument User Guide (Rev A.35) 165
The table below describes the Problem List status panels for the New Format window.
Digital Audio Selecting the General tab opens up an application screen that enables you
to define the digital audio parameters for a custom format or modify these
parameters of an existing format. (See “New Format - Digital Audio Tab” on
page 180 below for details on each of the parameters.)
AFD Selecting the General tab opens up an application screen that enables you
to define the AFD parameters for a custom format or modify these
parameters of an existing format. (See “New Format - AFD Tab” on page
183 below for details on each of the parameters.)
Entity Type Description / Function
Unit Pull-down menu Enables you to select the type of 882 unit that you are
viewing problems for. Options are:
• C/CA - 882C or 882CA
• D - 882D
• E - 882E
• EA/DP - 882E (HDMI), 882EA (HDMI), 882E
(DisplayPort)
•
Interface Pull-down menu Enables you to select the type of interface you are
defining a format for. Options are:
• Analog - Component analog (RGB or YPbPr)
• CVBS - Composite Video Baseband Signal
• S-Video - Y/C
• DVI - DVI from the DVI output
• HDMI-D - DVI from the HDMI output
• HDMI-H - HDMI
• SDI - SDI and HDSDI
Instrument
(Connection Status)
Status text field Shows the current connection status.
Error log
Red Dot Indicates that an error has occurred. In the future
warnings will be supported which will be yellow.
# (Number) An integer assigned to the error in the log list. This is a
number assigned in sequence as the errors occur.
Error # The 882 error number for a particular error type. The
error list can be found in “Error code descriptions”.
Description A text description of the error.
Tab Description / Function
