6 Chapter 1 Getting Started
HDMI Type A Connector Pinouts
Special Sync interface
Use the Special connector to output frame sync, line sync, composite sync, or a special
probe pulse. For more information, see Chapter 14, “Using Special Sync Output.”
Pin Signal Pin Signal Pin Signal
1 TMDS Data 2+ 7 TMDS Data0+ 13 CEC
2 TMDS Data2 Shield 8 TMDS Data0 Shield 14 Reserved (N.C.)
3 TMDS Data2- 9 TMDS Data0- 15 SCL
4 TMDS Data1+ 10 TMDS Clock+ 16 SDA
5 TMDS Data1 Shield 11 TMDS Clock Shield 17 DDC/SEC Ground
6 TMDS Data1- 12 TMDS Clock- 18 +5 V Power
19 Hot Plug Detect
