184 Chapter 5 Working with Formats
Extended From
Content Apert.
Map
Enables you to set the mapping type for mapping
CXAR-shaped image content into the extended
EXAR-shaped aperture.
Parameter: EXCX
Signal from
Extended Apert.
Map
Enables you to set the mapping type for mapping
EXAR-shaped image content into the SXAR-shaped
signal interface.
Parameter: SXEX
Bars
Left Sets the left side letterbox bars in pixels.
Right Sets the right side letterbox bars in pixels.
Top Sets the top letterbox bars in pixels.
Bottom Sets the bottom letterbox bars in pixels.
Heading Field Description / Function
