262 Chapter 9 Testing HDMI Sink Devices
3. Press the Options key. The following information appears on the 882’s display.
4. Choose the HP Bypass (hot plug bypass) item by pressing the adjacent soft key. A +
appears next to HP Bypass indicating enabled.
To manually set Source list of formats for non-EDID-compatible display:
When testing a display that is not EDID-compliant, the Source list is filtered to display only
those formats suitable for a particular interface type. For example, if you select CVBS, the
Source list does not include the VESA formats.
The 882’s format library is comprised of a set of format catalogs. You can set up the 882 to
show only the formats you want, in the order you want, when you browse through the
Source list. See “Format catalogs” on page 199 for details.
To use Emulate mode:
Emulate mode automatically sets color space, synchronization type, and other settings
based on the interface and format selected:
• For VGA interface, synchronization type and color space are automatically set and are
not changeable.
• For HDMI interface, synchronization type and color space are automatically set, but
color space can be changed.
1. Connect the 882 to the display you want to test.
2. Press the Sink key. The following information appears on the 882’s display.
3. Press the Options key. The following information appears on the 882’s display.
4. Choose the Emulate item by pressing the adjacent soft key. A + appears next to
Emulate indicating enabled.
Alternatively, to select the emulate mode through the command line interface, enter the
command shown below:
-EDID Formats CDF
+HP Bypass
-Emulate
Manufacturer:SNY
Product Code:144
Serial#:7011007
Week:20 Year:1998
-EDID Formats CDF
+HP Bypass
-Emulate
