882 Video Test Instrument User Guide (Rev A.35) 321
5. Enable lipsync testing in 882 as follows:
a. Press the Content key. The following information appears on the 882’s display.
b. Choose either the LipSyncB or LipSync image.
c. Press the Settings key. The following information appears on the 882’s display.
d. Set the LSGM setting to 1 by pressing the soft keys adjacent to the bottom row until
the cursor appears on the digit. Press the + or - keys to adjust the setting up or
down.
e. Press the Enter (Options) key to save the new setting.
Alternatively, to enable the 882 to measure lipsync correction through the command
line interface, enter the following command:
LSGX:LSGM 1 // Enables lipsync testing
LSGX:LSGU // Activates lipsync testing
6. Press the Content key. The following information appears on the 882’s display.
7. Choose the image to use for lipsync testing.
Acer1 Acer2
Acer3 Acer4
Acer5 Acer6
Acer7 Acer8
Image ->
LipSync ->
LSGM TLAT PLAT
1 0.0000 0 ->
Acer1 Acer2
Acer3 Acer4
Acer5 Acer6
Acer7 Acer8
To Next Page
