68 Chapter 12 CEC Interactive Troubleshooting Environment (ITE)
CEC1:PT 1 //configures the product (device) type
The table below lists the device (product) types and their codes.
CEC1:VID <vid> //configures the device vendor ID
CEC1:OSDN //configures the device OSDN
CEC1:PA 0 0 0 0 //configures the device physical address
4. Save the custom CEC device to a file:
CEC1:CECE //ends the CEC editing session
CEC1:CECS //saves the CEC device
5. Assign the custom CEC device to a connector:
CEC1:CECL myTV //assigns myTV to HDMI Rx port
CEC1:CECU //configures (uses) the assigned device
Configure generator to log CEC messages
The 882 can be configured to log CEC message and store them in a user defined
directory.
To enable CEC logging:
1. Enter the following command to enable logging on the HDMI connector:
CEC1:LOGG 1 //enables logging on the HDMI Tx output 1 port
CEC3:LOGG 1 //enables logging on the HDMI Rx ports
2. Enable all logging with the following command:
CECX:LOGM 6 //enables logging of all CEC messages
To disable CEC logging:
1. Enter the following command to disable CEC logging:
CEC1:LOGG 0 //disables logging on the HDMI Tx output 1 port
CEC3:LOGG 0 //disables logging on the HDMI Rx ports
Device Type Device Code
TV 0
Recording Device 1
Set Top Box 3
DVD 4
Audio System 5
