882 Video Test Instrument User Guide (Rev A.35) 31
To configure the 882’s serial port through the front panel or Virtual
Front Panel:
1. Press the Tools key. The Tools menu appears on the 882’s display as shown below.
2. Choose the System item by pressing the adjacent soft key. The System menu appears
on the 882’s display as shown below.
3. Choose the Serial item by pressing the adjacent soft key. The serial port settings
appear on the 882’s display.
Selec
4. Press the Settings key. The following information appears on the 882’s display:
5. To change the baud rate, do the following:
a. Position the blinking cursor on the baud rate setting. To do this, press the soft key
adjacent to the arrow by the baud rate setting to move the cursor left or right until
it appears on the baud rate setting.
b. Press the + or - keys to adjust the baud rate setting up or down.
6. To change the flow control state, do the following:
a. Position the blinking cursor on the flow control setting. To do this, press the soft
keys adjacent to the arrow by the flow control setting until the cursor appears on
the current flow control setting (N, H, or T).
b. Press the + or - keys to change the setting.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
CEC
Clock Clone*
CalFactor Server
Network About
Serial GPib
Serial Port
9600 baud
8 N 1
Serial Port
Set Params
BAUD FLOW ->
9600 N ->
To Next Page
