198 Appendix A Command Reference
Custom Image Draw
SPAX Set horizontal spacing
SPAY Set vertical spacing
UIDN Set test string in upper portion of SMPTE133 and Cubes images
XRES Set horizontal scaling factor
YRES Set vertical scaling factor
Command Description
ADOT Draw a single pixel
ANTI Use anti-aliasing
CENT Draw a small cross in center
CROS Draw a large cross in center
FORM Draw format data block
GRID Draw a color crosshatch with boxes
GRIH Draw equally spaced horizontal lines (grill)
GRIV Draw equally spaced vertical lines (grill)
HATI Draw inside-out color crosshatch with boxes
HATO Draw outside-in color crosshatch with boxes
LIMI Draw nine markers to define active video area
LINE Draw a line between two points
OVAL Draw an oval
PAGE Fill a rectangular area with a repeating character
RECT Draw a rectangle with sides parallel to axis of active video
SNUM Draw sequence step number (when using a sequence)
TBOX Draw information text box
TBXG Enable/disable display of information text box specified by TBOX
TEXT Draw text string
TRIA Draw a triangle
Command Description
