Quantum Data 881 - Page 683

882 Video Test Instrument User Guide (Rev A.35) 305
DVIC
Digital Video Identification Code
Class InfoFrame Packet
Description Writes the specified Video Identification Code (VIC) into the AVI InfoFrame.
Command syntax DVIC code
code
0 = unestablished format
1 - 34 = DVIC code corresponding to a format defined in EIA/CEA-861-C standard
(Section 4). See table below for DVIC codes.
For detailed information on these timings refer to the CEA-861-C specification.
DVIC Format Name NCPP
1
HRES
2
VTOT
3
1
DMT0659 1 640
525
1
DMT0660 1 640
525
2
480p59 1 720
525
2
480p60 1 720
525
2
480p59LH 1 720
525
2
480p60LH 1 720
525
3
480p59SH 1 720
525
3
480p60SH 1 720
525
4
720p59 1 1280
750
4
720p60 1 1280
750
5
1080i29 1 1920
1125
5
1080i30 1 1920
1125
6
480i2x29 2 720
525
6
480i2x30 2 720
525
6
480i2xL1 2 720
525
6
480i2xL2 2 720
525
7
480i2xS1 2 720
525
7
480i2xS2 2 720
525
8
240p2x_1 2 720
262
8
240p2x_2 2 720
262
8
240p2x_3 2 720
263
8
240p2x_4 2 720
263
8
240p2xL1 2 720
262
8
240p2xL2 2 720
262
8
240p2xL3 2 720
263
8
240p2xL4 2 720
263
9
240p2xS1 2 720
262
