882 Video Test Instrument User Guide (Rev A.35) 57
To activate the HDMI-H interface on the output port:
1. Press the Interface key. A listing of signal interfaces appears on the 882’s display as
shown below.
2. Choose the HDMI-H item by pressing the adjacent soft key. The interface is activated
and the port outputs the currently selected image and format.
Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Selects the HDMI-H interface
ALLU // Applies the interface setting to the 882
To verify the test set-up:
1. Press the Source key to access the list of formats.
2. Choose a high definition component format (for example, 720p50) by pressing the
adjacent soft key.
Alternatively, you can load the format with the following command:
FMTL 720p50
FMTU
3. Press the Content key to access the list of images.
4. Choose a suitable image (for example, SMPTE133) by pressing the adjacent soft key.
Alternatively, you can load the image with the following command:
IMGL SMPTE133
IMGU
To test the display:
1. Press the Source key and select the first test format.
Alternatively, you can load the format with the following command:
FMTL format_name
FMTU
2. Press the Content key and select the first test image.
Alternatively, you can load the image with the following command:
IMGL image_name
IMGU
3. Repeat steps 1 and 2 for all formats and test images. Use the following guidelines to
verify proper operation:
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*
HDMI-H
