70 Chapter 2 Testing Video Displays
To monitor the status of the keypad:
1. Press the Tools key. The Tools menu appears on the 882’s display.
When the keypad has been enabled there is an additional item in the Tools menu. This
is indicated by an arrow key. If you scroll down using the - key the following menu
appears:
2. Select the Keypad item to view the keypad status. The screen shown below appears.
This display shows the Mode which is either normal or Sequence and the current
format and image. The Exit enables you to exit from the menu without disabling the
keypad function.
Sequence ^
Probe
AFC
Keypad
Analyzer
ImgShift
Mode: Normal
FMT:720p60
IMG:Flat
Exit!
