Overall width:
With standard 25" wheels, including handrims with 6° camber: SW + 30 cm
91 cm with SD 48
112 cm with BH 45
from 6.4 kg
Maximum load:
Helium 120 kg
The choice of frames, forks and castors, as well as the rear wheel size (24", 25") determines the seat heights which can
be achieved.
Norm min. max. Norm min. max.
Overall length
with footrest
770 mm 1050 mm Seat surface
angle
0° 15°
Overall width 620 mm 760 mm Effective seat
depth
340 mm 480 mm
Folded length N/A N/A Effective seat
width
320 mm 460 mm
Folded width N/A N/A Seat height at
the front edge
430 mm 550 mm
Folded height N/A N/A Backrest angle 59° 105°
Total weight 6.4 kg 13.0 kg Back height 250 mm 450 mm
Weight of
the heaviest
individual part
- 2.1 kg with
24" rear
wheel
Distance from
the footrest to
the seat
220 mm 520 mm
Static stability -
downhill
10° 10° Angle from leg
to seat
92° 100°
Static stability
- uphill (with
anti-tip tube)
10° 10° Distance from
the armrest to
the seat
N/A N/A
Static stability -
sidewards
10° 10° Front position
of the armrests
N/A N/A
Dynamic
stability -
uphill Power
consumption
N/A N/A Handrim
diameter
540 mm 567 mm
Overcoming
obstacles
N/A N/A Horizontal axle
position
+ 56 mm + 11 mm
12.0 Technical Data
The wheelchair conforms to the following standards:
a) Requirements and tests for static strength, impact resistance and fatigue strength (ISO 7176-8) Yes •
b) Drive and control systems for power wheelchairs, requirements and test (ISO 7176-14) n.a. •
c) Environmental test in accordance with ISO 7176-9 n.a. •
d) Flammability resistance of upholstered parts in accordance with ISO 7176-16 (EN 1021-1/2) Yes •
