- 56 -
21.7. Printout Customization
GENERAL INFORMATION
Standard printout content can be customized. Using SCALES EDITOR.
freeware software it is possible to specify which data is to be printed, which
not. In order to download the software visit RADWAG website:
http://www.radwag.com. In order to download the software, visit RADWAG
website:
http://www.radwag.pl
22. TECHNICAL SPECIFICATIONS
Scales model: WTC 600
Max capacity 600g
Min capacity
0.5g
Readability [d] 0.01g
Verification unit [e] 0.1g
Tare range -600g
Repeatability 0.01g
Linearity ±0.02 g
Stabilization time 2 s
OIML class II
Weighing pan dimensions 128x128mm
IP rating IP 43
Operating temperature +15°C ÷ +30°C
Power supply
100 ÷ 240 V AC, 50 ÷ 60 Hz / 12 V DC
+ battery
Battery operating time 33h (average time)
Display LCD with backlight
RS232 x1
Net/gross weight 1.3 / 2kg
Packaging dimensions 330x230x140mm
