Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
117
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min Safe
Distance (cm)
RW‐9105‐5159
Flat DP
13
30°
26
36
RW‐9105‐4958
Flat DP
16
20°
20
26
Integrated
Flat DP
22
10°
19
45
RW‐9613‐4960
Flat DP
23
10°
19
51
Integrated
Flat DP
25
8°
16
45
RW‐9622‐5001
Flat DP
28
5°
12
40
RW‐9721‐5158
Dish DP
28
5.5°
11
36
RW‐9732‐4958
Dish DP
32
4°
7
36
Table 32: Frequency Band 5250‐5350 and 5470‐5725 MHz
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min Safe
Distance (cm)
RW‐9105‐5159
Flat DP
13
30°
14
20
RW‐9105‐4958
Flat DP
16
20°
11
20
Integrated
Flat DP
22
10°
5
20
RW‐9613‐4960
Flat DP
23
10°
4
20
Integrated
Flat DP
25a
8°
2
20
a. IMPORTATNT! The 80MHz channel bandwidth must not be operated with the 25 dBi integrated antenna.
The NEO and NEO DUO units bear the following FCC/IC IDs on the label. Refer to the Tables below:
FCC ID: Q3K‐NEO5X IC: 5100A‐NEO5X
This radio transmiers "IC: 5100A‐NEO5X" and “IC: 5100A‐JA496G" have been approved by Innovaon,
Science and Economic Development Canada to operate with the antenna types listed below, with the
maximum permissible gain indicated. Antenna types not included in this list that have a gain greater than
the maximum gain indicated for any type listed are strictly prohibited for use with this device.
The input impedance of the antenna is 50 Ohm.
The NEO and NEO DUO units as well as the JET –AIR and JET‐AIR DUO units must be installed so as to
provide a minimum separaon distance from bystanders as specied in the tables below.
