Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
116
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min. Safe
Distance (cm)
RW‐9105‐5158
Flat DP
19.0
17°
27
35
RW‐9613‐4960
Flat DP
23.0
10°
27
56
RW‐9622‐5001
Flat DP
28.0
5°
22
57
RW‐9721‐5158
Dish DP
28.0
5.6 °
22
57
RW‐9732‐4958
Dish DP
32.0
4°
18
57
The SU Integrated and SU Connectorized units bear the following FCC/IC IDs on the label. Refer to the Tables
below:
Contains FCC ID: Q3K‐5XSUALMOD Contains IC: 5100A‐5XSUALMOD
This radio transmier "Contains IC: 5100A‐5XSUALMOD" has been approved by Innovaon, Science and
Economic Development Canada to operate with the antenna types listed below, with the maximum
permissible gain indicated. Antenna types not included in this list that have a gain greater than the
maximum gain indicated for any type listed are strictly prohibited for use with this device.
The input impedance of all antennas is 50 Ohm.
The SU Integrated and SU Connectorized units must be installed so as to provide a minimum separaon
distance from bystanders as specied in the tables below:
Table 30: Frequency Band 5725‐5850 MHz
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min Safe
Distance (cm)
RW‐9105‐5159
Flat DP
13
30°
25.0
32
RW‐9105‐4958
Flat DP
16
20°
22.0
32
Integrated
Flat DP
22
10°
23.0
71
RW‐9613‐4960
Flat DP
23
10°
22.0
71
Integrated
Flat DP
25
8°
20.0
71
RW‐9622‐5001
Flat DP
28
5°
11.0
36
RW‐9721‐5158
Dish DP
28
5.5°
14.0
51
RW‐9732‐4958
Dish DP
32
4°
10.0
51
Table 31: Frequency Band 5150‐5250 MHz (FCC Only)

Radwin 5000 Specifications

General

Brand	Radwin
Model	5000
Category	Radio
Language	English
