RADWIN 5000 Installaon Guide
August 2023
79
Figure 101: IDU‐H power connectors and grounding lug.
• For direct DC connecon: The connectors are 3 pin in line female, with polaries (le to right) minus,
ground, plus, as shown:
• For AC connecon: To avoid damage to the IDU‐H, always use the AC/DC adapter and power plug
supplied by RADWIN.
Use only a safety approved IDU‐H according to IEC/EN/UL 60950‐1 or 62368‐1
with rated output voltage of 46‐55VDC and rated current of 4A max.
Ground the unit with a 14 AWG wire before applying power.

The IDU‐S is a high performance, managed GbE PoE switch with 1GbE, 2.5GbE and 10GbE interfaces. The
IDU‐S has a DC input, and is compable with most RADWIN PtP and PtMP radios.
The IDU‐S has the following connecons:
• Copper RJ45 POE Ports:
• 6x PoE ports operang in standard/legacy mode:
• 4x 2.5GbE POE ports (2.5G/1G/100M)
• 2x 1GbE POE ports (1G/100M/10M)
• SFP Ports:
• 2 x 10GbE,
• 2 x 1GbE,
• 2 x 1GbE (Combo)
• Ground wire connecon point
