Figure 108: Swivel vercally: SU PRO/AIR EMB
▪ Once alignment is complete, ghten the arm on the SU PRO/AIR EMB mounng kit (see Figure 77 for
the SU PRO/AIR EMB) or ghten the bolt on the standard mounng kit (see Figure 42 for an external
antenna, and Figure 50 for the SU Integrated).
▪ If the unit requires more ghtening, use the hex screw with a 5mm hex key as shown in Figure 76.
Figure 109: Tighten arm on mount: SU PRO/AIR EMB radio unit
Figure 110: Use hex screw to further ghten arm on mount: SU PRO/AIR EMB radio unit
