RADWIN5000ConfigurationGuide Release4.9.17 1‐4
KeyFeaturesofRADWIN5000 Introduction
RADWINManager
TheRADWINManagerisanSNMP‐basedmanagementapplicationwhichmanagesa
completesectoroverasingleIPaddress.
1.4KeyFeaturesofRADWIN5000
1.4.1General
» Ethernetconnectivity
» AdvancedOFDM&MIMO2x2fornLOSandNLOSperformance
» Enhancedinterferencemitigationcapability
» Inter&intrasitesynctoreduceselfinterference
» Multibandradios:Differentfrequenciesinthesameradiounit
» DedicatedBandwidthensuringSLA&latency
» Regulationssupported‐FCC/IC/ETSI/WPC/MII/Universal
» Upto32SubscriberUnitsperbasestation
» FullyintegratedwithRADWINLegacysolutions:
• BasestationcancoexistwithRADWIN2000andWinLink1000products
• CommonRADWINManager
» Nomadicsupport(standardinallbasestationmodels)
1.4.2BeamformingSolution(optional)
» Smartbeamformingantenna,integratedindedicatedbasestation
» On‐the‐flybeamformingcapabilityreducesinterference,increasesefficiency
» Narrowbeam
» Supportforethernet‐basedsynchronization
» IntegratedGPSsynchronizationcapability
TheWebInterfacefortheSUPRO/AIRandforlegacyHBSandHSUradiosare
different.
1.5What’sNewinRelease4.9.17
» EnhancedperformancefortheSUPRO/AIRavailableviaanon‐integratedexternal
antenna.
» ThecurrentmodulationforboththeSUandthebasestationisshowninthe
AntennaAlignmentwindowoftheSUPRO/AIR(seeAntennaAlignmentonpage 5‐
10)
