RADWIN5000ConfigurationGuide Release4.9.17 12‐6
RunningSpectrumViewfromtheHBS SpectrumView
12.8RunningSpectrumViewfromtheHBS
ChooseEntiresectorandclickStart.Youareofferedthefollowingcautionarymessage:
IfitisacceptabletodroptheserviceclickYes.Theprocessingmayappeartohavestopped‐
butitisnotcompleteuntilalloftheShowbuttonsforselectedHSUsareenabled.
HereistheresultfortheHBS:
Show/Hidepointvalues
SavetheanalysistoaCSVfile
Clearallsectormemberanalyses
fromthedisplay(Theycanbe
shownagain)
Eachbuttonfunctionappliestoallofthesectormembersatonce.
Table12‐1:SpectrumViewAnalysisDisplayButtonsfunctionality(Continued)
Butto
n
Purpose

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
