RADWIN5000ConfigurationGuide Release4.9.17 2‐17
SectorStatusPanel RADWINManagerOverview
2.7.2SectorStatusPanel
Sector‐levelparametersaresetbeforethebasestationis activatedandareapplicablefor
eachHSUinthesector.
Figure2‐17:SectorStatuspanel
SectorID:Thenameofthesector.WhenconfiguringHSUs,makesuretheirSectorIDisthe
sameasthathere,otherwiseconnectionmaynotbepossible.
Frequency,Band:TheFrequencyandFrequencyBandinuseinthesector.
ChannelBW:Bandwidthofthespecificchannel.Thiscanbeconfigured.
Status:IndicateswhethertheHBShasbeenactivatedornot.
CIRResources:IndicatewhatpercentageoftheallocatedCIRresourcesarebeingusedbythe
sectoratan
ygivenmoment.
2.7.3BaseStationPanel
TheBaseStationpanelshowsbasicinformationfortheconnectedBaseStation.
Helpside
arrow
LinkBudgetCalculator
AppNote“LinkBudget
Calculator”
CheckUpdates
About
Table2‐4:HBSmainbuttonbarfunctions
MenuItem Purpose CrossRef erence

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
