RADWIN5000ConfigurationGuide Release4.9.17 12‐5
SpectrumViewDisplayFunctionButtons SpectrumView
TheremainingcontrolsontheSpectrumViewmainwindowrelatetoSpectrumViewdata
manipulation.Wewillcovertheminthenextsectionusingaliveanalysis.
12.7SpectrumViewDisplayFunctionButtons
SpectrumViewdatamanipulationfunctionsareprovideonthetopbuttonbar:
Table12‐1:SpectrumViewAnalysisDisplayButtonsfunctionality
Butto
n
Purpose
Show/HideAntennaA
Show/HideAntennaB
Show/Hideaverage
Show/Hidecurrentchannel
(HSUsonly)
Show/Hidemaximum
Show/HideDFSinformation

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
