RADWIN5000ConfigurationGuide Release4.9.17 3‐27
RegisteringanomadicHSUforservice InstallingaSector
f. TheMaximumInformationRatechoseninStep10.isshownherebythe
numbersinred,andbytheredlines onthegraph.Hadthesenumbersbeen
higherthanthemaximumpossiblethroughput,theywouldnotappear,as
theywouldnotaffectanything.
g. TheresourceallocationchoseninStep9.isshownherebothgraphically
andasanumbervalue.WhatappearsontheHSUcardisrelevantforthe
selectedHSUonly,buttheCIRresourcebarshownonthetopleftreflects
thethisallocationforthewholesector.
12. RepeattheabovestepsforeachfixedHSU.
3.10RegisteringanomadicHSUforservice
 ToconfigurenomadicHSUsfromtheHBS:
1. OpentheHBSConfigurationwindowandthenitsNomadicTab:
Figure3‐6:HBSNomadicConfiguration
